Local Platform Mesh with LLM & Chat UI

Platform Mesh turns Kubernetes operators into managed services. A provider writes an operator once, registers it through KCP, and every customer gets self-service access through a workspace without ever touching the cluster where the operator runs.

That sounds abstract. This tutorial makes it concrete.

You will set up a full Platform Mesh environment on your laptop, register two real service providers, and then (switching to the customer's perspective) provision a private LLM and a Chat UI that talks to it. Everything runs on a single Kind cluster, but the architecture is identical to what runs in production.

Step	Role	What you do
1	Platform team	Set up local Platform Mesh (Kind + KCP)
2	Provider team	Install Private LLM on the local setup
3	Provider team	Install Chat UI on the local setup
4	Customer	Create the consumer (demo) workspace
5	Customer	Bind to the provider APIs (APIBinding)
6	Customer	Create an LLMInstance
7	Customer	Create a ChatUIInstance wired to the LLM
8	Customer	Access the Chat UI and talk to the model

---

Scenario Overview

Imagine a platform team that wants to offer two services to its internal customers: a private LLM inference endpoint and a chat interface. The platform team builds two Kubernetes operators and registers them in Platform Mesh. A customer binds to the provider APIs and creates instances without needing to know where or how those operators run.

This tutorial puts you in both roles. First you are the platform team, deploying operators and registering them as providers. Then you become the customer, creating service instances through the KCP API.

The two providers:

Provider	What it does	What the customer creates
Private LLM	Runs a llama.cpp inference server	An LLMInstance CR with a model name and replica count
Chat UI	Deploys a per-tenant Open WebUI wired to an OpenAI-compatible backend	A ChatUIInstance CR pointing to a credentials Secret

What makes this interesting is the composition. Chat UI does not bundle its own LLM; it consumes one. The customer creates an LLM first, gets a Secret with the endpoint, then passes that Secret to the Chat UI. Two independent providers, connected through a standard interface.

Architecture

In production, KCP runs on a dedicated cluster and each provider has its own MSP (Managed Service Provider) cluster. Locally, everything runs in a single Kind cluster, but the logical boundaries are the same: provider workspaces are isolated from consumer workspaces, sync agents bridge the control plane to the workload layer, and operators only see CRs that belong to their APIExport.

Local Platform Mesh architecture: everything runs in a single Kind cluster, but the logical layers (provider, consumer, sync, workload) mirror the production setup

Both providers follow the same split: one umbrella chart for the workload side (operator + sync agent on Kind), one for the KCP side (APIExport in the provider workspace).

Prerequisites

• Docker (or Podman)
• Kind (Kubernetes in Docker)
• kubectl
• Helm 3
• Task (optional, you can run the scripts directly)
• yq, mkcert: used by local-setup scripts
• krew: used to install the kcp kubectl plugins in Step 1
• ~10 GB free disk space (Kind cluster + model download)

Plan around 25 min on a warm machine: about 10 of those are task local-setup; the rest is Helm plus waiting for the model to download.

For detailed prerequisite setup across operating systems and container runtimes, see the Platform Mesh local-setup README.

Key Concepts

• KCP Workspaces: the multi-tenant control plane. Each provider and consumer organization gets its own isolated workspace.
• APIExport & APIBinding: the provider/consumer contract. A provider publishes an APIExport; a consumer binds to it in their workspace.
• API Sync Agent & PublishedResource: the bridge between KCP and a workload cluster. CRs created in KCP are virtual; the sync agent mirrors them to real clusters and syncs status back.

Part 1: Building the Platform

Step 1: Set up Local Platform Mesh

Clone helm-charts, check out the release tag, run the local setup, and install the kcp kubectl plugins. The tag pins the Platform Mesh OCM component used by local setup; do not edit local-setup/kustomize/components/ocm/component.yaml.

git clone https://github.com/platform-mesh/helm-charts.git
cd helm-charts
git checkout 0.3.0

task local-setup

kubectl krew index add kcp-dev https://github.com/kcp-dev/krew-index.git || true
kubectl krew install kcp-dev/kcp kcp-dev/ws kcp-dev/create-workspace

Point your shell at the two kubeconfigs:

export KCP="$(pwd)/.secret/kcp/admin.kubeconfig"
export KIND="$(pwd)/.secret/kind/kubeconfig"
mkdir -p "$(dirname "$KIND")" && kind get kubeconfig --name platform-mesh > "$KIND"
export KUBECONFIG=$KCP
export DEMO_USER=tutorial@example.com    # must look like an email; Step 4's org initializer validates the format

Apply two one-time runtime adjustments:

# Use 127.0.0.1 to avoid localhost address-family ambiguity.
yq -i '
  .clusters[].cluster.server |= sub("https://localhost:", "https://127.0.0.1:") |
  .clusters[].cluster."tls-server-name" = "localhost"
' "$KCP"

# CoreDNS: make KCP virtual-workspace hostnames reachable from inside pods.
(
  export KUBECONFIG=$KIND
  TRAEFIK_IP=$(kubectl get svc -n default traefik -o jsonpath='{.spec.clusterIP}')
  kubectl get configmap coredns -n kube-system -o yaml | \
    TRAEFIK_IP=$TRAEFIK_IP yq eval '.data.Corefile |= sub("kubernetes cluster.local",
      "hosts {\n    " + strenv(TRAEFIK_IP) + " localhost kcp.localhost root.kcp.localhost llm.test\n    fallthrough\n}\nkubernetes cluster.local")' | \
    kubectl apply -f -
  kubectl rollout restart deploy coredns -n kube-system
  kubectl rollout status deploy coredns -n kube-system --timeout=90s
)

Verify the two endpoints:

KUBECONFIG=$KIND kubectl get nodes
kubectl kcp workspace tree

Step 2: Install Private LLM

Private LLM lives in two places: the operator and sync-agent on the Kind cluster, and the APIExport on KCP. Install both halves directly from the published OCI charts.

Create the provider workspace on KCP:

kubectl kcp workspace use :root
kubectl create-workspace providers --type=root:providers --ignore-existing
kubectl kcp workspace use :root:providers
kubectl create-workspace private-llm --type=root:provider --ignore-existing

Install the workload side on Kind:

kubectl kcp workspace use :root
KUBECONFIG=$KIND helm install private-llm \
  oci://ghcr.io/apeirora/charts/private-llm-msp-app --version 2.10.1 \
  --namespace private-llm --create-namespace \
  --set global.publicHost=llm.test \
  --set kcpKubeconfig.inClusterServerUrl=https://frontproxy-front-proxy.platform-mesh-system.svc.cluster.local:8443 \
  --set-file kcpKubeconfig.adminContent=$KCP

Install the KCP side in the provider workspace:

kubectl kcp workspace use :root:providers:private-llm
helm install private-llm-pm \
  oci://ghcr.io/apeirora/charts/private-llm-pm-app --version 2.10.1 \
  --namespace private-llm --create-namespace

Sync agent pods may restart once or twice during the first ~90 seconds, while the KCP-side install finishes publishing its endpoint slice. This is expected.

Wait for the sync agent to publish the provider resources before moving on:

KUBECONFIG=$KIND kubectl -n private-llm rollout status deployment/private-llm --timeout=3m
kubectl get apiexport llm.privatellms.msp \
  -o jsonpath='{range .spec.resources[*]}{.name}{"\n"}{end}'

The APIExport resources must include llminstances and apitokenrequests.

For the full details and troubleshooting, see the Private LLM local installation guide.

Step 3: Install Chat UI

Chat UI follows the same umbrella-chart pattern as Private LLM and is published the same way.

Create the provider workspace on KCP:

kubectl kcp workspace use :root:providers
kubectl create-workspace chat-ui --type=root:provider --ignore-existing
kubectl kcp workspace use :root:providers:chat-ui

Install the workload side on Kind:

KUBECONFIG=$KIND helm install chat-ui \
  oci://ghcr.io/apeirora/charts/chat-ui-msp-app --version 0.10.6 \
  --namespace chat-ui --create-namespace \
  --set kcpKubeconfig.inClusterServerUrl=https://frontproxy-front-proxy.platform-mesh-system.svc.cluster.local:8443 \
  --set-file kcpKubeconfig.adminContent=$KCP

Install the KCP side in the provider workspace:

helm install chat-ui-pm \
  oci://ghcr.io/apeirora/charts/chat-ui-pm-app --version 0.10.6 \
  --namespace chat-ui --create-namespace

Wait for the sync agent to publish the Chat UI resource before moving on:

KUBECONFIG=$KIND kubectl -n chat-ui rollout status deployment/chat-ui --timeout=3m
kubectl get apiexport ui.privatellms.msp \
  -o jsonpath='{range .spec.resources[*]}{.name}{"\n"}{end}'

The APIExport resources must include chatuiinstances.

For the full details and troubleshooting, see the Chat UI local installation guide.

Both providers are now registered in KCP and their sync agents are idle, waiting for a customer to create something.

Part 2: Using the Platform

Step 4: Create the Consumer Workspace

Customer resources live under two Account CRs: the org Account creates the org workspace (and its workspace types), and a child Account creates the per-user workspace your resources actually land in.

Create the org Account:

kubectl kcp workspace use :root:orgs

until kubectl create -o yaml -f - 2>/dev/null <<EOF | grep -q 'allowed: true'; do sleep 2; done
apiVersion: authorization.k8s.io/v1
kind: SubjectAccessReview
spec:
  user: ${DEMO_USER}
  resourceAttributes:
    verb: create
    group: core.platform-mesh.io
    resource: accounts
    version: v1alpha1
EOF

kubectl create --as="$DEMO_USER" -f - <<'EOF'
apiVersion: core.platform-mesh.io/v1alpha1
kind: Account
metadata:
  name: demo
spec:
  type: org
  displayName: Demo Org
EOF

kubectl wait account/demo --for=condition=Ready --timeout=3m

Wait for the org authorization store, then switch into the new workspace:

until kubectl get store demo >/dev/null 2>&1; do sleep 2; done
kubectl wait store/demo --for=condition=Ready --timeout=3m

KUBECONFIG=$KIND kubectl rollout restart deployment/rebac-authz-webhook -n platform-mesh-system
KUBECONFIG=$KIND kubectl rollout status deployment/rebac-authz-webhook -n platform-mesh-system --timeout=90s

kubectl kcp workspace use :root:orgs:demo

Create the child Account. In local setup, the authorization webhook can occasionally keep returning NoOpinion for the new org workspace until it is restarted. The bounded retry below restarts it and rechecks the SAR instead of waiting forever.

account_create_allowed() {
  kubectl create -o yaml -f - 2>/dev/null <<EOF | grep -q 'allowed: true'
apiVersion: authorization.k8s.io/v1
kind: SubjectAccessReview
spec:
  user: ${DEMO_USER}
  resourceAttributes:
    verb: create
    group: core.platform-mesh.io
    resource: accounts
    version: v1alpha1
EOF
}

allowed=false
for attempt in 1 2 3; do
  for _ in $(seq 1 30); do
    if account_create_allowed; then
      allowed=true
      break 2
    fi
    sleep 2
  done

  KUBECONFIG=$KIND kubectl rollout restart deployment/rebac-authz-webhook -n platform-mesh-system
  KUBECONFIG=$KIND kubectl rollout status deployment/rebac-authz-webhook -n platform-mesh-system --timeout=90s
done

if [ "$allowed" != true ]; then
  echo "Timed out waiting for account create authorization in root:orgs:demo" >&2
  exit 1
fi

kubectl create --as="$DEMO_USER" -f - <<'EOF'
apiVersion: core.platform-mesh.io/v1alpha1
kind: Account
metadata:
  name: tutorial
spec:
  type: account
  displayName: Tutorial Account
EOF

kubectl wait account/tutorial --for=condition=Ready --timeout=3m

Switch into the tutorial workspace and create the default namespace where your service instances will land:

kubectl kcp workspace use :root:orgs:demo:tutorial   # stay here for the remaining steps
kubectl create namespace default --dry-run=client -o yaml | kubectl apply -f -

Step 5: Bind the Provider APIs

An APIBinding is how a consumer workspace subscribes to a provider's APIExport. Think of the APIExport as a service catalog entry the provider publishes, and the APIBinding as the customer saying "yes, give me access". After the binding is accepted, the provider's CRDs appear in the consumer workspace: kubectl get llminstances and kubectl get chatuiinstances start working inside root:orgs:demo:tutorial, even though the CRDs themselves are still owned by the provider.

The sync agent needs to read your Secrets and write Events: permission claims that the binding must accept. Skip them and the binding still goes green, but every sync-agent request comes back forbidden.

kubectl apply -f - <<'EOF'
apiVersion: apis.kcp.io/v1alpha2
kind: APIBinding
metadata:
  name: llm-binding
spec:
  reference:
    export:
      path: root:providers:private-llm     # provider workspace
      name: llm.privatellms.msp            # APIExport (exposes LLMInstance + APITokenRequest)
  permissionClaims:
  - {group: "", resource: secrets,    verbs: ["*"], selector: {matchAll: true}, state: Accepted}
  - {group: "", resource: namespaces, verbs: ["*"], selector: {matchAll: true}, state: Accepted}
  - {group: "", resource: events,     verbs: ["*"], selector: {matchAll: true}, state: Accepted}
---
apiVersion: apis.kcp.io/v1alpha2
kind: APIBinding
metadata:
  name: chat-ui-binding
spec:
  reference:
    export:
      path: root:providers:chat-ui         # provider workspace
      name: ui.privatellms.msp             # APIExport (exposes ChatUIInstance)
  permissionClaims:
  - {group: "", resource: secrets,    verbs: ["*"], selector: {matchAll: true}, state: Accepted}
  - {group: "", resource: namespaces, verbs: ["*"], selector: {matchAll: true}, state: Accepted}
  - {group: "", resource: events,     verbs: ["*"], selector: {matchAll: true}, state: Accepted}
EOF

Verify both bindings become Ready:

kubectl wait apibinding/llm-binding --for=condition=Ready --timeout=3m
kubectl wait apibinding/chat-ui-binding --for=condition=Ready --timeout=3m
kubectl get apibindings

until kubectl api-resources --api-group=llm.privatellms.msp | grep -q '^llminstances'; do sleep 2; done
until kubectl api-resources --api-group=ui.privatellms.msp | grep -q '^chatuiinstances'; do sleep 2; done

Step 6: Create an LLMInstance

LLMInstance is now a type in your workspace. Create one: the sync agent mirrors it to the Kind cluster, the operator downloads the model and runs llama.cpp, and status flows back to KCP:

kubectl apply -f - <<'EOF'
apiVersion: llm.privatellms.msp/v1alpha1
kind: LLMInstance
metadata:
  name: demo-llm
  namespace: default
spec:
  model: gemma-3-1b-it
  replicas: 1
EOF

kubectl wait llminstance/demo-llm --for=condition=Ready --timeout=8m
kubectl get llminstance demo-llm

Step 7: Request a Token and Create a ChatUIInstance

Chat UI doesn't bundle its own model; it consumes one over an OpenAI-compatible API. The configuration procedure (create an APITokenRequest, get a Secret back, hand it to the Chat UI) is the same pattern production deployments use; you're just running it locally.

Create an APITokenRequest. The LLM operator generates an auth token, writes OPENAI_API_URL and OPENAI_API_KEY into a Secret named <request-name>-token, and the sync agent mirrors that Secret back into your consumer workspace:

kubectl apply -f - <<'EOF'
apiVersion: llm.privatellms.msp/v1alpha1
kind: APITokenRequest
metadata:
  name: demo-llm-token
  namespace: default
spec:
  instanceName: demo-llm
  description: Chat UI access token
EOF

kubectl wait apitokenrequest/demo-llm-token --for=jsonpath='{.status.phase}'=Ready --timeout=3m
TOKEN_SECRET=$(kubectl get apitokenrequest demo-llm-token -o jsonpath='{.status.secretName}')

Wait until the mirrored Secret is readable in the consumer workspace:

until kubectl get secret "$TOKEN_SECRET" >/dev/null 2>&1; do sleep 2; done

Create the ChatUIInstance, pointing it at the token secret:

kubectl apply -f - <<EOF
apiVersion: ui.privatellms.msp/v1alpha1
kind: ChatUIInstance
metadata:
  name: demo-chat
  namespace: default
spec:
  credentialsSecretRef:
    name: $TOKEN_SECRET
EOF

Wait for the Chat UI operator to deploy Open WebUI and report back:

kubectl wait chatuiinstance/demo-chat --for=condition=Ready --timeout=8m

Step 8: Access the Chat UI

Port-forward to the Open WebUI pod on the Kind cluster:

(
  export KUBECONFIG=$KIND
  CHAT_NS=$(kubectl get chatuiinstances -A -o jsonpath='{.items[0].metadata.namespace}')
  kubectl port-forward -n "$CHAT_NS" svc/demo-chat-chatui 8080:8080
)

Open http://localhost:8080. Gemma 3 1B auto-selects in the model picker; it shows as /models/gemma-3-1b-it-Q4_K_M.gguf (llama.cpp registers models by their file path).

On local CPU-only runtimes, Gemma inference is slow. A first reply can take several minutes because Open WebUI sends a much larger prompt than a basic smoke-test query. The UI isn't stuck, Gemma is just thinking.

The first Open WebUI start can also take a minute or two while Kind pulls the image and Open WebUI downloads its startup assets. ContainerCreating or an initial Provisioning phase is expected during that first boot.

What Just Happened

Take a step back and look at what you built. The tutorial had two parts, and the boundary between them is the whole point.

Part 1 was platform work: deploying operators, creating provider workspaces, registering APIs. Each provider had a workload-side install on Kind and a KCP-side install in its provider workspace.

Part 2 was customer work: binding to APIs, creating CRs, getting back status. The customer never knew which cluster the operators ran on, never needed cluster credentials, never wrote a Helm chart. They created short YAML documents against the KCP API and got managed services back.

The flow:

1. Customer creates an LLMInstance in their workspace: a request, not an instruction
2. LLM sync agent mirrors the CR to the workload cluster
3. Private LLM operator reconciles: downloads the model, creates Deployment and Service
4. Status flows back through the sync agent; the customer sees Ready
5. Customer creates a ChatUIInstance with a credentials Secret, composing two services through a standard interface
6. Chat UI sync agent mirrors the CR and Secret; the operator gets both in the same namespace
7. Chat UI operator reconciles: deploys Open WebUI, injects credentials
8. Status flows back; the customer has a working Chat UI

This separation (providers build operators, the platform handles multi-tenancy and delivery, customers create simple CRs) is what Platform Mesh enables. The local setup compresses the infrastructure, but the contracts between the layers are identical to production.

Cleanup

kind delete cluster --name platform-mesh

Troubleshooting

For operator-specific issues, see each project's local installation guide:

• Private LLM troubleshooting
• Chat UI troubleshooting
• Platform Mesh local-setup troubleshooting

Common Issues

Symptom	Cause	Fix
task local-setup hangs during Kind creation and kubelet logs contain could not detect clock speed	The older kindest/node:v1.35.0 image can fail on some arm64 Docker setups	Use the pinned guide commit b0ff8e91, which uses kindest/node:v1.35.1
Sync agent logs contain frontproxy-front-proxy...:6443: i/o timeout	PM 0.4.0-build.30 exposes the in-cluster front-proxy Service on 8443, while the provider chart defaults still point at 6443	Keep the Step 2 and Step 3 kcpKubeconfig.inClusterServerUrl=...:8443 value on the MSP-side Helm installs
helm install hits the wrong cluster	KUBECONFIG is set to $KCP by default; MSP-side installs must prefix with KUBECONFIG=$KIND	Re-run with KUBECONFIG=$KIND helm install ... on the MSP-side command
kubectl against localhost:8443 returns http: server gave HTTP response to HTTPS client	localhost can resolve to the wrong local listener for this setup	Apply the 127.0.0.1 kubeconfig patch in Step 1
KUBECONFIG=$KIND kubectl … returns connection refused against a 127.0.0.1:<port> that doesn't match the running Kind container	Docker reassigns the Kind API-server port on each container restart and the file at $KIND still has the old port	Refresh $KIND from the live cluster: kind get kubeconfig --name platform-mesh > "$KIND"
Creating the demo Account fails with cannot patch resource "accounts" and NoOpinion	kubectl apply --server-side uses the patch verb, while local org onboarding grants the demo user create for Accounts	Use the Step 4 kubectl create --as="$DEMO_USER" commands. If a failed retry created tutorial directly under root:orgs, run kubectl kcp workspace use :root:orgs, then delete it with kubectl delete account tutorial
Creating the demo or tutorial Account fails with cannot create resource "accounts" and NoOpinion	The rebac-authz-webhook's apiexport-cluster-provider raced the Store reconciler: Store.status.storeId was empty when it tried to register the new logical cluster, so the cluster was dropped and never retried	Run the Step 4 flow as written: it waits for the Store, rolls the webhook so it re-registers cleanly, and SAR-polls before each impersonated create. If you hit it on an already-broken stack, KUBECONFIG=$KIND kubectl rollout restart deployment/rebac-authz-webhook -n platform-mesh-system and rerun the failing block
Creating LLMInstance fails with no matches for kind "LLMInstance"	The Private LLM sync agent has not published llminstances into the provider APIExport yet	Run the Step 2 rollout and APIExport resource checks. If private-llm is CrashLooping, inspect KUBECONFIG=$KIND kubectl -n private-llm logs deploy/private-llm --tail=50
Creating ChatUIInstance fails with no matches for kind "ChatUIInstance"	The Chat UI sync agent has not published chatuiinstances into the provider APIExport yet	Run the Step 3 rollout and APIExport resource checks. If chat-ui is missing or unhealthy, inspect KUBECONFIG=$KIND kubectl -n chat-ui logs deploy/chat-ui --tail=50

Further Reading

• Private LLM: Architecture
• Chat UI: Architecture
• Platform Mesh local-setup: Developer Guide
